Vertical Profile Lidar

Category:
LiDAR
Brand:
ZX Lidars EURO
Type:
ZX300M V2
vertical-profile-lidar

Description

The Vaisala WindCube and ZX300M are wind Lidar systems. These devices can measure a vertical wind profile with 12 programmable heights for the WindCube and 10 programmable heights for the ZX300M. Output of the devices includes horizontal wind speed, wind shear, turbulence intensity and wind direction.

Technical details

Model: WindCube V2.1

Range: 40 m to 200 m

Wind speed accuracy: 0.1 m/s

Wind speed range: 0 m/s to 60 m/s

Direction accuracy: 2 deg

Operating temperature: -30 deg C to +45 deg C

Operating humidity: 0 to 100% RH

Ingress Protection: IP67

Weight: 46 kg system without accessories

85 kg system with accessories packaged in the transport case

Eye safety: Class 1M IEC/EN 60825-1

Model: ZX300M V2

Range: 10 m to 300 m

Wind speed accuracy: 0.1 m/s

Wind speed range: 1 m/s to 80 m/s

Direction accuracy:

Operating temperature: -40 deg C to 50 deg C

Operating humidity: 0 to 100% RH

Ingress Protection: IP68

Weight: 53 kg incl power supply and mounting frame

78 kg system with accessories packaged in the transport case

Eye safety: Class 1M IEC/EN 60825-1

Applications

These Lidars are typically used in wind resource assessment, research projects or validation measurements.

TNO is accredited by RvA for IEC 61400-50-2 Wind measurement – Application of ground-mounted remote sensing technology (Registration number: L 324) and TNO has all the tools and working procedures in place to provide reporting according to the IEC 61400-50-2 standard.

Since 2020 TNO performs validation measurements of Floating Lidar Systems (FLS) near Lichteiland Goeree (LEG). More information is available on the TNO website: https://offshorewind-measurements.tno.nl/
